Even the smallest KX has disc brakes to demonstrate the power of effective braking to new riders in Kawasaki's smallest motocrosser. Remember, championship winners start here.
| Engine type | Væskekjølt, 2-takts En-sylindret |
|---|---|
| Compression ratio | 8.4:1 |
| Valve system | Stempelets bladventil |
| Bore x stroke | 44.5 x 41.6 mm |
| Displacement | 64 cm³ |
| Fuel system | Forgasser |
| Lubrication | Bensinmiks |
| Starting system | Kick-start |
| Ignition system | Elektronisk CDI |
| Transmission | 6-trinns |
|---|---|
| Clutch | Våt multi-disk |
| Primary reduction ratio | 3.500 (77/22) |
| Gear ratios 1st | 2.846 (37/13) |
| Gear ratios 2nd | 2.125 (34/16) |
| Gear ratios 3rd | 1.722 (31/18) |
| Gear ratios 4th | 1.428 (30/21) |
| Gear ratios 5th | 1.217 (28/23) |
| Gear ratios 6th | 1.083 (26/24) |
| Final drive | Kjede |
| Final reduction ratio | 3.615 (47/13) |
| Frame type | Dobbelrør, strekkfast stål |
|---|---|
| Rake | 27,0 ° |
| Trail | 60 mm |
| Wheel travel front | 210 mm |
| Wheel travel rear | 240 mm |
| Tyre, front | 60/100-14 M/C (29M) |
| Tyre, rear | 80/100-12 41M |
| L x W x H | 1,590 x 760 x 955 mm |
| Steering angle L R | 40° / 40° |
| Wheel base | 1,120 mm |
| Ground clearance | 305 mm |
| Fuel capacity | 3.8 liter |
| Seat height | 760 mm |
| Curb mass* | 60 kg |
| Front brake type | Enkel skive |
|---|---|
| Front brake diameter | Ø 180 mm |
| Front brake caliper type | Ett-stempel |
| Rear brake type | Enkel skive |
| Rear brake diameter | Ø 180 mm |
| Rear brake caliper type | Ett-stempel |
| Front suspension type | Teleskopgaffel med 4-veis returdemping |
| Front suspension diameter | Ø 33 mm |
| Rear suspension type | Bottom-Link Uni-Trak med trykksatt demping, justerbar forspenning og trinnløs returdemping |
